Signal Light + Work Light ECE R10 R148 R65 / SAE

LED Scene light/reverse+warning lamp
1.Power : 24PCS 1W OSRAM Whiteleds
+12PCS Amber 1W led / 18 PCS Blue 1W led
2.Lumen:3000LM
3.Voltage:10-30V DC
4.Beam Pattern: Flood
5.Dimension: 179.7*60.9*28mm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP69K
9. Guarantee: 3 years
10.Material: Diecast aluminum housing;
PC Lens

LED Scene light/reverse+warning lamp
1.Power : 24PCS 1W OSRAM Whiteleds
+12PCS Amber 1W led / 18 PCS Blue 1W led
2.Lumen:3000LM
3.Voltage:10-30V DC
4.Beam Pattern: Flood
5.Dimension: 179.7*60.9*28mm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP69K
9. Guarantee: 3 years
10.Material: Diecast aluminum housing;
PC Lens

LED Work light/ Reversing Light with SIGNAL light (Driving +stop+direction)
1.Power : 6PCS 3W white leds,12PCS 1W amber/red/blue leds
2.Lumen: 1600LM 3.Voltage:10-30V DC 4.Beam Pattern: Flood + Flash
5.Dimension: 74*91*32mm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP69K
9. Guarantee: 3 years
10.Material: Diecast aluminum housing; PC Lens

LED Work light/ Reversing Light with Warning light AMBER/BLUE/DUAL COLORS
1.Power : 6PCS 3W white leds,12PCS 1W amber/red/blue leds
2.Lumen: 1600LM 3.Voltage:10-30V DC 4.Beam Pattern: Flood + Flash
5.Dimension: 74*91*32mm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP69K
9. Guarantee: 3 years
10.Material: Diecast aluminum housing; PC Lens

48W LED Strobe Beacon blue color
passed ECE R65 CLASS2
            ECE R10
            SAE CLASS1
            IP67

LED WARNING LIGHT BAR
1.Voltage:10-30V DC
2.Beam Pattern: 19 flash patterns
3.Working Temperature:-45 ~60°C
4.Waterproof: IP67
5.Material: PC Lens +PC housing
6. Mounting: Gutter
7. Guarantee: 3 years
8. ECE R10 R65 CLASS2 / SAE J845 CLASS1
9. Length: 59inch / 1.45 M
10. Power: 105W  516 LEDS

LED WARNING LIGHT BAR
1.Voltage:10-30V DC
2.Beam Pattern: 19 flash patterns
3.Working Temperature:-45 ~60°C
4.Waterproof: IP67
5.Material: PC Lens +PC housing
6. Mounting: Gutter
7. Guarantee: 3 years
8. ECE R10 R65 CLASS2 / SAE J845 CLASS1
9. Length: 47 inch / 1.2 M
10. Power: 95W 420 LEDS

1,Lightbar Function customizable.
2,Water-proof IP67 grade
3,Certification R65 Class2,R10,SAE Class 1
4,Full encapsulated for moisture,vibration and
corrosion resistance
5.Color: AMBER / BLUE / RED / WHITE OR DUAL COLORS

LED Warning Light with sidemark
1.Power : 6PCS 4W LEDs / 51PCS 0.2W LEDs
2.Voltage:10-30V DC
3.Beam Pattern: 19 flash
4.Dimension: 130*40*11mm
5. LED Color : Amber +Amber
6.Working Temperature:-45 ~60°C
7. Material: ; Aluminum alloy housing +PC Lens
8. Mount: Two bolts with a rubber
9.Waterproof: IP69K
10.Guarantee: 3 years

LED Warning Light with front position/reversing function
1.Power : 6PCS 4W LEDs / 51PCS 0.2W LEDs
2.Voltage:10-30V DC
3.Beam Pattern: 19 flash
4.Dimension: 130*40*11mm
5. LED Color : amber or blue warning + white rear position
6.Working Temperature:-45 ~60°C
7. Material: ; Aluminum alloy housing +PC Lens
8. Mount: Two bolts with a rubber
9.Waterproof: IP69K
10.Guarantee: 3 years

SAE J595 and ECE R65 certified high power warning output
Water-proof IP69K grade Multi-units synchronization in simultaneous or alternating flash.
Full encapsulated for moisture,vibration and corrosion resistance Aluminium base for efficient heat dissipation maximum durability

SAE and ECE R65 certified high power warning output.
Water-proof IP69K grade Multi-units synchronization in simultaneous or alternating flash.
Full encapsulated for moisture,vibration and corrosion resistance Aluminium base for
efficient heat dissipation and maximum durability .
3-years warranty.

SAE and ECE R65 certified high power warning output.
Water-proof IP69K grade Multi-units synchronization in simultaneous or alternating flash.
Full encapsulated for moisture,vibration and corrosion resistance Aluminium base for efficient heat dissipation and maximum durability .
3-years warranty.

LED Scene light/reverse+warning lamp
1.Power : 24PCS 1W OSRAM Whiteleds
+12PCS Amber 1W led / 18 PCS Blue 1W led
2.Lumen:3000LM
3.Voltage:10-30V DC
4.Beam Pattern: Flood
5.Dimension: 179.7*60.9*28mm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP69K
9. Guarantee: 3 years
10.Material: Diecast aluminum housing;
PC Lens

LED Scene light/reverse+signal (driving / stop / direction)
1.Power : 24PCS 1W OSRAM Whiteleds
+12PCS  1W LED signal light
2.Lumen:3000LM
3.Voltage:10-30V DC
4.Beam Pattern: Flood
5.Dimension: 179.7*60.9*28mm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP69K
9. Guarantee: 3 years
10.Material: Diecast aluminum housing;
PC Lens

16W ROUND LED Work Light 1.Power : 16PCS 1W OSRAM leds
2.Lumen:1600LM
3.Voltage:10-30V DC
4.Beam Pattern: Flood
5.Dimension: 75x75x43cm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP67
9. Guarantee: 3 years
10.Material: Diecast aluminum housing;
PC Lens

36W Round LED Work Light 1.Power : 36PCS 1W OSRAM leds
2.Lumen:3600LM
3.Voltage:10-30V DC
4.Beam Pattern: Flood
5.Dimension: Φ110x49cm
6.Working Temperature:-45 ~60°C
7.Color Temp :5000~6500K
8.Waterproof: IP67
9. Guarantee: 3 years
10.Material: Diecast aluminum housing;
PC Lens
